ETHERNET PoE

Ethernet PoE (Power over Ethernet) Port to receive network stream content.

Web Server / System Control etc.


HDMI

HDMI Port with a resolution up to 4K2K60.

Selectable Audio digital (AC3) or analog (L/R)
Adjustable Audio Delay / Channel volume for each channel.
HDMI 4:2:0 color depth


Analog Audio L/R

Analog Audio L/R via 3,5 mm Jack Plug.

Analog Audio L/R for passive Speaker

Analog Audio active Phoenix Port for passive Speaker


RS-232

For the hole device control.

Standard Baudrate: 115200/8/1
(Different Baudrate adjustable)

Cabel-connection 1:1


USB

For Picture / Audio / Video Playback
Device Update

SD-Card Reader

For Picture / Audio / Video Playback

IR-Input

3,5 mm jack plug for infrared receiver


Remote control

For a convenient and practical commissioning of the device.
Remote control can be configured with up to four addresses.
e.g.: FB1=>IRD1


External 5V Power Supply

External screwable power supply 5V


VESA Mounting Interface

VESA Mounting Interface Breadboard 75mm x 75mm


Database Readback

Message read back function from database


App Support

App-Support for control systems like e.g. Netflix, Amazon Prime Video, DAZN, InternetRadio, Spotify, BIZZ.fm, etc.

Please contact us for App requests


Power Button

Device Power-Up Button
