Tuner 1

Satellite Tuner.

NOTE: Tuner with F-Connector 75Ω for a save connection.

Tuner 2

Second Cabel/Terrestrial Tuner.

NOTE: Tuner with F-Connector 75Ω for a save connection.

HDMI

HDMI Port with a resolution up to 4K2K60.

Selectable Audio digital (AC3) or analog (L/R)
Adjustable Audio Delay / Channel volume for each channel.
HDMI 4:2:0 color depth

ETHERNET 1

Ethernet Port for network control.

Web Server / Control System etc.

ETHERNET 2

1 GBit Ethernet Port for IP-Streaming.

SPTS ( Singel Program Transport Stream)
MPTS ( Multi Program Transport Stream).

eSATA

Port for 2 x 2TByte or 1 x 4Tbyte (Read). 3 GBit/s data signaling for Full-HD recording.

NAS-configuration and controlled by IRD
Time-controlled recording and Playback with Loop-function.

RS-232

For the hole device control.

Standard Baudrate: 115200/8/1
(Different Baudrate adjustable)

Cabel-connection 1:1

Analog Audio ( L/R )

Adjustable Audio Delay / Channel volume for each channel.

RCA-Connector with 75Ω

Analog Audio ( PHOENIX )

Adjustable Audio Delay / Channel volume for each channel.

5 pol. Phoenix analog audio balanced

Analog Audio ( XLR )

Adjustable Audio Delay / Channel volume for each channel.

2 x XLR 3pol. analog audio balanced

AC3 7.1 / 5.1 Downmix

For digital Audio AC3 (Dolby Digital) conversion to an analog Audio L/R signal.

Downmix for HDMI-, L/R-, PHOENIX- or XLR-Port
End use e.g.: RTL HD / SAT HD / ANIXE HD

Digital Audio ( S/Pdif )

Adjustable Audio Delay / Channel volume for each channel.
RCA-Connector with 75Ω

IR-Input

3,5 mm jack plug for infrared receiver

Remote control

For a convenient and practical commissioning of the device.
Remote control can be configured with up to four addresses.
e.g.: FB1=>IRD1

Power Supply

110 - 240 V AC

Redundant power supply

Redundant power supply designed for two phases.
Thermo-controlled fan monitoring.

Automatic switching to redundant power supply if defective will detect (warning function)

PCMCIA-Interface

Support for Conditional Access module like Alphacrypt (SKY, ORF), Conax, Irdeto, etc.

App Support

App-Support for control systems like e.g. Netflix, Amazon Prime Video, DAZN, InternetRadio, Spotify, BIZZ.fm, etc.

Please contact us for App requests
